Black Pear 2

The Black Pear 2 allows a building management system (BMS) to monitor and control air-conditioning units on a system from one of five manufacturers, without the need for a central controller.

It has been designed as a plug-in replacement for the original Black Pear BMS interface, with similar configuration options, all accessible via the touch screen or built-in web browser interface.

Black Pear 2 Facia suitable for cabinet / panel mount projects.

Facia sold separately from the BP2


Microtrol have launched their all-new fan coil controller The Dyaus-1

The new DayuS-1 is the most advanced and flexible fan coil controller to date. Designed to work with the most common valve types on the market, Thermal, motorised, & 0-10v.

Installation setup and control of the DyauS-1 is simple with the use of the Pyrus full colour touchscreen wall controller.

Designed to work on the Black Pear network with all fan coils. This gives it a true one stop solution. With this flexibility, the DyauS-1 can also utilise the full colour BP2 Interface,

which give amazing control and access to BMS all in one box (BacNet, Modbus & Trend). Along with the STC full colour central controller, 3rd party peripherals can be added to the BP network via our TXIO interface and others

All this and more make the DyauS-1 the most advanced fan coil controller in the market today.

Hardware Features

240V AC 50Hz @ 10VA max supply input (excluding fan and heater)
Built-in 24V AC output for valves/actuators
3x 0-10V @ 5mA analogue outputs
3x 10kΩ thermistors inputs
2x Volt-free digital inputs
4x TRIAC outputs (configuration links for 24V or 240AC @ 500mA)
3x Low-current relay outputs (240V AC @ 1A)
1x High-current relay output (240V AC @ 10A)
1x heartbeat LED

Controller Features

Individual PI-controllers for heating and cooling
Supports 2 or 4-pipe system
1x PWM controller for electric heater relay (proportional to heating PID)
Analogue, motorised, and thermal valve actuator controllers
Fan controllers with soft-start, start/stop-delay, and destratification logic (analogue/3-speed relays)
Anti-frost and changeover hysteresis logic
Energy-saving via comfort, eco, and standby mode (configurable setpoint deadband)
Configurable debouncing delay for all digital inputs
Alarms (fan motor, condensate pump)

Communication Features User-interface via colourful touchscreen Pyrus wall remote controller (built-in 15V DC supply)
BMS protocols interface via BlackPear2 (BACnet, Trend, Modbus, web portal, touchscreen)
Header-Follower grouping (daisy-chain) *
PC-link via USB micro-B (firmware update)


Screenshot 2020-11-17 at 09.55.28.png

Wall-mounted air conditioning room controller

We are a leading provider of innovative integration solutions to the BMS and HVAC industries. To address the demanding requirement of this industry we are proud to introduce Black Pear. The Black Pear family of interfaces, controls and communication solutions are leading the way, providing the most cost effective and reliable products the HVAC market has seen.



The new Black Pear range of HVAC interfaces and controllers

Offering a completely revised approach to the integration of HVAC systems into BMS. Black Pear simplifies the interface by providing a direct connection to the HVAC communications network thereby eliminating the need for additional costly gateways.


ECO Datenspeicher

The Black Pear ECO Datenspeicher (‘ECO Data Store’) has been designed for Toshiba to meet the German government’s new energy efficiency/monitoring scheme, with their Estia heat-pump boilers.

A resolution of 10 minutes gives a very detailed picture of the heating efficiency and energy usage of your system.

The data is stored locally within the device (10+ years storage capacity) and can be viewed with any web browser connected to the local network.
